6424M ebm-papst Compact Fan

Brand :: ebmpapst

Model:: 6424M | ebm-papst 24V 12W DC Axial Fan for Electronics Cooling

Type:: Compact Fans

Industry:: Automation

Description:: The ebm-papst 6424M is a high-performance dc axial fan engineered for electronics and industrial equipment. It provides reliable airflow and efficient thermal management for demanding equipment.

Datasheet:: 6424M | ebm-papst 24V 12W DC Axial Fan for Electronics Cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	24
Size(mm)	17215051
Max.Air Flow(m³/h)	350
Max.Pressure(Pa)	124
Input Power(W)	12
Speed(rpm)	2850
Noise(db)	52

Product Features

High Airflow Cooling

The ebmpapst 6424M is a compact DC axial cooling fan for industrial automation and electronic equipment. Its space-saving format fits control cabinets, embedded electronics and automation assemblies that need a direct airflow path for continuous heat removal.

Key selection data includes a 24 V supply, airflow up to 350 m³/h, and maximum pressure of 124 Pa. The axial flow path provides efficient cooling, while pressure performance helps move air through guards, filters and restricted passages. The datasheet identifies ball-bearing motor support for durable motor support. Listed noise is 52 dB at the specified test point. Matching the electrical supply and duty point supports energy-efficient, reliable operation and long service life.

The 6424M suits equipment builders and repair teams seeking a compact industrial fan. Confirm system resistance, wiring, mounting and ambient limits. Applied correctly, it delivers dependable service as a long-life cooling fan.

Application Industry

Automation Cooling

6424M Supports reliable heat removal in automation controllers, machine electronics and compact industrial control equipment.

Product Insights

Other Series Comparison — 6424M vs Variants

How the 6424M compares to nearby Other series variants:

Model	252H	255M	3214J/2N-335	3214JH4
Air Flow	—	—	—	—
Power	— W	— W	— W	— W
Noise	— dB	— dB	— dB	— dB
Size	— mm	— mm	— mm	— mm

All Other series fans from Hengrui include performance curves, mounting instructions and factory warranty. Contact us for project-specific selection.

Typical Applications — 6424M Other Fan

Condenser Cooling: The 6424M axial fan excels at condenser heat rejection in refrigeration and HVAC.

AHU Air Handling: Engineered for integration into Air Handling Units.

Industrial Process Ventilation: Machinery cooling, enclosure ventilation and process air movement. Hengrui provides custom engineering support.

Frequently Asked Questions

Is the 6424M compatible with my equipment?

Compare 24 V, 172*150*51 mm, airflow demand and connection details with your equipment.

Where can the 6424M be used?

It is a compact DC axial fan listed for automation cooling and ventilation applications.
