AFB0724VH Delta Blower Fan

Brand :: Delta

Model:: AFB0724VH | Delta Electronics 24VDC 6.48W Axial Fan for Server and Power Supply Cooling

Type:: Blower Fans

Industry:: Data Center Cooling

Description:: The 70 mm AFB0724VH axial fan is listed for server cooling on 24VDC. A 25.4 mm body depth defines the required clearance, while its 6.48 W input distinguishes it from the supplied 12VDC version of similar speed.

Datasheet:: AFB0724VH | Delta Electronics 24VDC 6.48W Axial Fan for Server and Power Supply Cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	24
Size(mm)	707025.4
Max.Air Flow(m³/h)	88.4
Max.Pressure(Pa)	107.9
Input Power(W)	6.48
Speed(rpm)	5500
Noise(db)	47.5

Product Features

DC Equipment Cooling

In power-supply equipment, Delta AFB0724VH supplies the forced-air element of the cooling system. As a brushless DC axial fan, it is intended for integration into a defined mechanical and electrical assembly.

The 24 V DC supply requirement gives electrical designers a clear basis for matching the fan to the equipment power architecture. The series uses ball-bearing motor support for rotational durability, giving OEMs a service-life-oriented construction for equipment cooling. Matching the fan curve to the finished air path supports efficient cooling; free-air flow alone does not determine installed performance.

Choose it for a model-specific cooling requirement, with connector, operating conditions and airflow direction checked before release to production.

Application Industry

Server & Storage

Delta AFB0724VH serves server and storage equipment, helping remove heat from processors, drives and other heat-producing assemblies. Airflow supports stable equipment temperatures.

Power Supplies

Delta AFB0724VH supports cooling in power-supply equipment. Air circulation around power-conversion components helps manage electrical conversion losses, supporting dependable power delivery.

Telecommunications

In telecommunications equipment, Delta AFB0724VH helps remove heat from densely arranged electronic assemblies. The cooling solution addresses continuous communication duty to support service continuity.

Industrial Controls

For industrial control equipment, Delta AFB0724VH provides equipment cooling around controllers and electronic modules. Managing heat accumulated within enclosures helps maintain stable automation operation.

Frequently Asked Questions

Is AFB0724VH suitable for a high-reliability cooling system?

Suitability depends on thermal margin, operating temperature, alarm or feedback requirements and system redundancy. Qualify AFB0724VH at the actual duty point; the model name alone is not a reliability guarantee.

Which certifications or standards apply to AFB0724VH?

RoHS Compliant is listed in the workbook. Obtain the current exact-model declaration and datasheet before claiming safety approvals, ingress protection or international compliance.

What should be checked if AFB0724VH fails to start?

Isolate power first. Verify the approved supply, connector, polarity or phase, control-enable input and any obstruction; follow the exact specification and do not bypass protection circuits.

What operating speed is listed for AFB0724VH?

5500 rpm is listed in the workbook. This value alone does not establish adjustable-speed capability; confirm the control input and permitted operating range in the exact datasheet.

What equipment is AFB0724VH intended to cool?

AFB0724VH is listed for Server and Power Supply cooling. Confirm the installed airflow demand, pressure loss and ambient conditions before approval.

Can AFB0724VH directly replace another fan?

A matching outline alone does not prove compatibility. Check 24VDC, mounting dimensions, connector, pinout, airflow direction, control signals and the required pressure-flow point.
