AFB0924SH Delta Blower Fan

Brand :: Delta

Model:: AFB0924SH | Delta Electronics 24VDC 9.6W Axial Fan for Server and Power Supply Cooling

Type:: Blower Fans

Industry:: Data Center Cooling

Description:: AFB0924SH provides axial ventilation for server and power-supply enclosures using 24VDC. The 92 x 92 x 25 mm fan lists 174 m3/h maximum airflow, with a 4800 rpm rotor and 9.6 W input specification.

Datasheet:: AFB0924SH | Delta Electronics 24VDC 9.6W Axial Fan for Server and Power Supply Cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	24
Size(mm)	929225
Max.Air Flow(m³/h)	174
Input Power(W)	9.6
Speed(rpm)	4800
Noise(db)	53

Product Features

DC Equipment Cooling

Delta AFB0924SH serves telecommunications equipment as a brushless DC axial fan. Equipment builders can use its mechanical format to establish forced ventilation near heat-producing parts.

Its listed 92 x 92 x 25 mm format defines the space needed for installation, helping designers reserve room for adjacent components and cable routing. The series combines ball-bearing construction with UL 94V-0 materials, addressing mechanical durability and component flammability requirements. Keeping inlet obstructions clear helps preserve useful airflow without spending extra power on avoidable system losses.

Choose it for a model-specific cooling requirement, with connector, operating conditions and airflow direction checked before release to production.

Application Industry

Server & Storage

Delta AFB0924SH serves server and storage equipment, helping remove heat from processors, drives and other heat-producing assemblies. Airflow supports stable equipment temperatures.

Power Supplies

Delta AFB0924SH supports cooling in power-supply equipment. Air circulation around power-conversion components helps manage electrical conversion losses, supporting dependable power delivery.

Telecommunications

In telecommunications equipment, Delta AFB0924SH helps remove heat from densely arranged electronic assemblies. The cooling solution addresses continuous communication duty to support service continuity.

Industrial Controls

For industrial control equipment, Delta AFB0924SH provides equipment cooling around controllers and electronic modules. Managing heat accumulated within enclosures helps maintain stable automation operation.

Frequently Asked Questions

What equipment is AFB0924SH intended to cool?

AFB0924SH is listed for Server and Power Supply cooling. Confirm the installed airflow demand, pressure loss and ambient conditions before approval.

What installation space is required for AFB0924SH?

The workbook lists 92 x 92 x 25 mm. Confirm overall depth, hole pattern, connector clearance and guard or inlet-ring dimensions in the exact mechanical drawing.

What operating speed is listed for AFB0924SH?

4800 rpm is listed in the workbook. This value alone does not establish adjustable-speed capability; confirm the control input and permitted operating range in the exact datasheet.

Is AFB0924SH suitable for a high-reliability cooling system?

Suitability depends on thermal margin, operating temperature, alarm or feedback requirements and system redundancy. Qualify AFB0924SH at the actual duty point; the model name alone is not a reliability guarantee.

What should be checked if AFB0924SH fails to start?

Isolate power first. Verify the approved supply, connector, polarity or phase, control-enable input and any obstruction; follow the exact specification and do not bypass protection circuits.
