GTW040FUC15E-M001 Delta Axial Fan

Brand :: Delta

Model:: GTW040FUC15E-M001 | Delta Electronics 230VAC 330W EC Axial Fan for Server and Precision Cooling

Type:: Axial Fans

Industry:: Data Center Cooling

Description:: GTW040FUC15E-M001 combines EC axial fan cooling with a nominal 230VAC supply for server and precision equipment. Its listed 5350 m3/h maximum airflow and 1650 rpm speed define this model's ventilation profile.

Datasheet:: GTW040FUC15E-M001 | Delta Electronics 230VAC 330W EC Axial Fan for Server and Precision Cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	230
Size(mm)	φ528 x 154
Max.Air Flow(m³/h)	5350
Max.Pressure(Pa)	198
Input Power(W)	330
Speed(rpm)	1650
Noise(db)	72

Product Features

EC Axial Cooling

Equipment manufacturers evaluating precision cooling equipment can consider Delta GTW040FUC15E-M001, an EC axial fan. The fan supports heat removal by keeping air moving through the selected cooling path.

The listed 330 W power rating is relevant to supply sizing and the system energy budget; actual consumption depends on the operating duty. The matching document lists IP54 protection, helping engineers assess enclosure exposure and installation suitability. Keeping inlet obstructions clear helps preserve useful airflow without spending extra power on avoidable system losses.

For OEM design-in and replacement sourcing, confirm the full suffix, connector and mounting pattern to support dependable service in the intended assembly.

Application Industry

Precision Cooling

Delta GTW040FUC15E-M001 supports cooling in precision cooling equipment. Air circulation around heat-exchange sections helps manage continuous temperature-control demand, supporting stable environmental conditions.

Server & Storage

Delta GTW040FUC15E-M001 serves server and storage equipment, helping remove heat from processors, drives and other heat-producing assemblies. Airflow supports stable equipment temperatures.

Telecommunications

For telecommunications equipment, Delta GTW040FUC15E-M001 provides equipment cooling around densely arranged electronic assemblies. Managing continuous communication duty helps maintain service continuity.

Frequently Asked Questions

What equipment is GTW040FUC15E-M001 intended to cool?

GTW040FUC15E-M001 is listed for Server and Precision cooling. Confirm the installed airflow demand, pressure loss and ambient conditions before approval.

What installation space is required for GTW040FUC15E-M001?

The workbook lists φ528 x 154 mm. Confirm overall depth, hole pattern, connector clearance and guard or inlet-ring dimensions in the exact mechanical drawing.

What supply voltage should be used for GTW040FUC15E-M001?

230VAC is listed for GTW040FUC15E-M001. Verify the allowable input range, phase, frequency where applicable, polarity and wiring diagram in the exact specification.

Does GTW040FUC15E-M001 support speed control?

The filter data does not confirm a control interface. Check the exact-model datasheet and wiring for PWM, analog control, FG/RD feedback or fixed-speed operation before connection.

Is GTW040FUC15E-M001 suitable for a high-reliability cooling system?

Suitability depends on thermal margin, operating temperature, alarm or feedback requirements and system redundancy. Qualify GTW040FUC15E-M001 at the actual duty point; the model name alone is not a reliability guarantee.

Which certifications or standards apply to GTW040FUC15E-M001?

RoHS Compliant is listed in the workbook. Obtain the current exact-model declaration and datasheet before claiming safety approvals, ingress protection or international compliance.
